Atach Close

Basic Info.

Model NO.	BB300-150
Feature	No Clogging
Accept OEM or Not	Yes
Material	304/316/316L
Transport Package	Plywood Casing
Specification	BB
Trademark	ATACH
Origin	China
HS Code	8413709990
Production Capacity	5000unit/Year

Product Description

- Name of pump: Atach Close-Coupled close Impeller Stainless Steel Self Priming Pump 50/60Hz BB300-150
- Pump Type: Self-priming Pump
- Pump model: BB300-150
- Pump brand: ATACH
-Installation Type: Horizontal Close-Coupled
- Impeller Quantity: 1 pcs
- Rated pump capacity: 6.8 m3/h
- Rated pump head: 13 m
- Power/speed: 0.75 Kw/2900 r.p.m
- Power supply:Single phase/220V/50HZ, 3 phase/380V/50HZ
(also supply special voltage,special frequency, explosion-proof motor, High efficiency and energy saving motor )
- Material Supply: SUS304,SUS316,SUS316L
- Shaft Seal: Mechanical seal
- Inlet / outlet : 25mm*25mm
- NPSH: 4 m
- Main usage:

1. Food Processing

2. Medicine

3.Chemical Industry

4. Environmental Protection

5.Water Treatment

6.Electroplate

7. Others

If you need other specifications or parameters of BB series Self-priming Pump, please contact us in detail.
